Energic Motoculteur 103 – Bineuse Avant.
Energic Motoculteur 103 – Bineuse Avant.
The Energic motoculteur 103 with its single wheel “Monoroue” when fitted with a front cultivator (bineuse) forms a stable 3 wheel assembly.
Without lifting devices/relevage; This assembly offers the simplicity of use. Excellent manoeuvrability at the end of the rows, by just tilting the assembly up slightly in a balanced way a U-turn can be easily effected. (on reasonably flat terrain).
With lifting device/relevage; By pulling on cords that are attached to the assembly on the wheels the bineuse assembly can be lifted and locked in place. After the turn/manoeuver the cord is again pulled to release the locking devices thus lowering the assembly to the ground.
The lifting device is made up of cord operated deformable parallelograms which can e locked on each wheel in the working or raised positions. They are operated by a cord passing under the handlebars.
Differing working depths can be obtained by the positioning of the tools/implements on the assembly. And also by some degree by the height of the assembly.
Adjustment of the setting implement intervals is important to prevent unearthing of crops. And the maximization of the effect of using the Bineuse avant assembly.
***********
The equipment used in/on the Bineuse avant – see diagram.
Formations/combinations;
To work at three intervals and two and a half intervals; 3 diagrams below.
Rows with a spacing of 20 cms; 5 units size 57 or 62 width 140 cms.
4 rows with a spacing of 25 cms to 30 cms apart. This can comprise of 3 hearts HEY (large), width 220 mm, OR 3 hearts 56 bis width 220mm. Both with a Rasette right and left.
4 rows with a spacing of 25 cms, 30 cms or 35 cms apart. This can comprise of 4 Racettes 54 bis at 160mm width. And 4 Racettes of 55 bis at 160 mm width.
************
To work at one interval and two and a half intervals; 2 diagrams below
2 rows with a spacing of 40 cms, 45 cms or 50 cms apart. This can comprise of 3 hearts HEY 57 bis width 140 mm. OR 3 hearts 62 bis width 140 mm, with 2 rasettes 54 bis 160 mm and 2 rasette 55 bis width 160 mm.
2 rows with a spacing of 50 cms, 55 cms or 60 cms apart. This can comprise of 3 hearts HEY 57 bis width 220 mm. OR 3 hearts 62 bis width 220 mm with 2 rasettes 54 bis 160 mm and 2 rasette 55 bis width 160 mm.
**************
To work at three interval and two and a half intervals; 2 diagrams below
2 rows with a spacing of 20 cms to 25 cms apart. 8 Pics Fouilleur/spikes 52 bis width 45 mm.
4 rows with a spacing of 30 cms to 35 cms apart. 13 Pics Fouilleur/spikes 52 bis width 45 mm.
************
To work at one interval and two and a half intervals; 3 diagrams below
2 rows with a spacing of 40 cms to 45 cms apart. 8 Pics Fouilleur/spikes 52 bis width 45 mm
.
2 rows with a spacing of 50 cms – 55 cms – 60 cms apart. 11 Pics Fouilleur/spikes 52 bis width 45 mm.
**************
